What is SEOOW PORTABLE CORD - 600V?

What is SEOOW Portable Cord - 600V?

Many customers browsing our store here at Wire & Cable To Go stumble upon our SEOOW portable Cord and ask us the difference between this cord & our SOOW Portable cord.

The main difference is in the construction of the cord's jacket.

SEOOW- 600v  stands for:

S - Service
E - Thermoplastic Elastomer
OO - Oil Resistant Insulation & Oil Resistant Jacket
W - Water & Weather Resistance

Read more

What’s the Difference Between SOOW, SEOOW, and STOW Portable Cord?

And what does that J mean?Willy_lasso-768x683




Buying flexible portable cord can be a confusing process—the existence of several different types of SO cord makes it hard to choose the right one. To help anyone going through this process, we’ve compiled a quick cheat sheet to explain the differences between them.

First, let’s take note of the similarities: each of these multi-conductor power cables can be used in a variety of applications that require wiring with superior flexibility and durability such as portable tools and equipment, portable appliances, small motors, and associated machinery.


Types of SO portable cord & their unique properties


SOOW & SJOOW


The most popular SO cord, these portable cords have a flexible thermoset rubber jacket, making them known for their abrasion resistance and heat resistance, while maintaining cost effectiveness.










SOOW


S for Service

OO for Oil-resistant insulation and Oil-resistant jacket

W for Weather and Water resistance.

Rated to: 600 Volts
Temp. Range: -40 to 90ºC
Size: 18 to 2 AWG
Conductors: 2 to 40 Conductors

SJOOW


Same as SOOW but the J is for Junior—a Junior cable is rated to 300V rather than 600V.





Rated to: 300 Volts
Temp. Range: -40 to 90ºC
Size: 18 to 10 AWG
Conductors: 2 to 4 Conductors

soow portable cord



Shop SOOW




Shop SJOOW




SEOOW & SJEOOW


The thermoplastic elastomer jacket is what sets this SEOOW family apart from the SOOW & SJOOW portable cords. This thermoplastic contains chemical resistance characteristics of PVC & flexible properties of rubber.

In more general terms the SEOOW is a high-quality flexible cord engineered with plastic characteristics and rubber jacketed material while the SOOW counterpart is only made up of a rubber jacket. The SEOOW is also more resistant to water than SOOW and can be used at lower temperatures—the SEOOW temperature range is –50ºC to 105ºC.










SEOOW


S for Service

E for Thermoplastic Elastomer

OO for Oil-resistant insulation and Oil-resistant jacket

W for Weather and Water resistance.

Rated to: 600 Volts
Temp. Range: -50 to 105ºC
Size: 18 to 2 AWG
Conductors: 2 to 5 Conductors

SJEOOW


Same as SEOOW but the J is for Junior—a Junior cable is rated to 300V rather than 600V.







Rated to: 300 Volts
Temp. Range: -50 to 105ºC
Size: 18 to 10 AWG
Conductors: 2 to 4 Conductors

seo-b



Shop SEOOW




Shop SJEOOW




STOW & SJTOW


These cords have similar resistant properties as the SOOW and the SEOOW, thought not to the same extent. The STOW and SJTOW also have a thermoplastic jacket, making them the least flexible of the SO portable cords. However, they work great for consumer applications, portable lights and power extensions.










STOW


S for Service

T for Thermoplastic

O for Oil-resistant jacket

W for Weather and Water resistance.

Rated to: 600 Volts
Temp. Range: -40 to 60ºC
Size: 18 to 10 AWG
Conductors: 2 to 4 Conductors

SJTOW


Same as STO but the J is for Junior—a Junior cable is rated to 300V rather than 600V.







Rated to: 300 Volts
Temp. Range: -20 to 60ºC
Size: 18 to 10 AWG
Conductors: 2 to 5 Conductors

sjto-b



Shop STOW




Shop SJTOW






The across-the-board durability and versatility of the SO cord is what make it the most popular electrical cord on the market for consumers. Depending on your specific portable cord needs—flexibility, temperature resistance, affordability—there is an SO cord that will do the job.

Unique Customers w/ Diverse Projects - Copper Wire, Security Cable, Welding Cable & More...

We love learning about all the different types of projects our customers are working on.

With thousands of customers stemming from all different parts of the country we are fortunate enough to speak with such an eclectic group of people working on such a wide range of projects.

We thought it would be nice to share a few examples below of how some of our customers apply our wire & cable.

Please note, every project and application is different and we always recommend double checking with a certified electrician/technician before making a purchase to be on the safe side:)

Bill in North Dakota using 18/5 SOOW Portable Cord for signal lights.

Duke in Virginia using 2 gauge welding cable for solar battery charging.



Teddy in Arizona using 1/0 THHN Copper Building Wire for his new residential sub-panel.

Lance in Illinois using 18 Gauge 10 Conductor Security Cable as access control cable for his commercial properties.

Alex in California using 14/3 SJOOW Portable Cord for theatrical stage lighting.

George in New Jersey using 1/0 4C Type W Power Cord for a marina installation.

Alfonso in Florida using 20 Gauge 5 Conductor Unshielded Communication Cable for his pool cover controller.

Benjamin in New York using 6 Gauge THHN Copper Wire in a conduit for his workshop sub-panel.

Tom in Washington using 8/3 SEOOW Portable Cord for air compressor extension cord.

Lisa in Alabama using 12 gauge 2 conductor landscape lighting cable for their re-designed home residence.

Charlotte in Wisconsin using 18/7 Tray Cable for a wiring harness.

Are you working on a new project and have questions?

If so please give us a call as we would love to hear from you.

855-880-8010

Thanks for stopping by!

Your pal,

Willie

WireAndCableYourWay.com

Thermoplastic Elastomer (TPE) - A Word From Willie The Wire & Cable Guy

Many customers looking at our SEOOW & SJEOOW Portable Cords call in to Wire & Cable To Go asking what's Thermosplastic Elastomer (TPE) insulation?

Thermoplastic Elastomer (TPE) is a fine blend of polymers containing containing both thermoplastic & elastomeric properties.  When processed & combined these properties create a rubbery and plastic material.

Overall, thermoplastic elastomer is used in SEOOW & SJEOOW Portable Cords as an insulation jacket that contain both rubber & plastic characteristics.

According to Coleman Cable who pioneered the SEOOW & SJEOOW cable, prior to 1981 there were two basic types of cable - Rubber (SOW) & PVC (STOW).  Coleman created the SEOOW & SJEOOW by constructing the cable using Thermoplastic Elastomer (TPE) technology giving customers an excellent option of a cord containing the chemical resistance of PVC (plastic) & the flexible characteristics of rubber.

TPE gives customers in the commercial, industrial & construction fields a flexible portable cord that is durable, abrasion resistant,  light in weight, easy to strip & fully recyclable!

If this is a type of cable and jacket that may interest you please see our SEOOW & SJEOOW links below which can provide all specs on the SEOOW & SJEOOW Portable Cords:

Click here to view our SEOOW category >>

Click here to view our SJEOOW category >>

Please call 855-880-8010 if you have any questions!

Thanks for stopping by.

Your Pal,
Willie



Looking For Yellow Flexible Portable Cords by the Foot?

Yellow SO Portable Cord

Does your project require a yellow flexible portable cord?

If so, Wire & Cable To Go supplies many different types of 300v & 600v yellow cords.

From sizes 10awg to 18awg, we offer flexible yellow cords with 2 conductors, 3 conductors & 4 conductors.

Whether its an SJ 300v yellow cord or an SO 600v yellow cord, we have many different options for our customers.

Although we only list our 12/3c sjoow yellow cord on our website we do stock more types and recommend you calling us directly at 855-880-8010 or sending us an email through our contact page to inquire about availability & pricing.

We offer these cables by the foot and can ship them out same day with an estimated arrival time within 1-3 business days.

Feel free to click here to visit our website and learn more about our wide selection of wire & cable products.
