West Penn 2598G8, RG8/U - 10AWG 50 Ohm Coaxial Cable CMP Rated, 1000ft

Min: 1 ft., Max: 10000 ft. To order multiple lengths, simply enter the desired footage into the quantity fields. Each length will be delivered on its own spool.
Add a length

 Free Shipping on all orders over $1000

West Penn 2598G8, RG8/U - 10AWG 50 Ohm Coaxial Cable CMP Rated, 1000ft

SKU
WP2598G8

Product Details

Learn everything you want to know about this product to make an informed purchase

RG8/U - 10AWG 50 Ohm Coaxial Cable CMP Rated RF 50 Ohm Video, Wireless Mic Distribution

Application:

RF 50 Ohm Video, Wireless Mic Distribution

Conductor:
Solid Bare Copper

Insulation:
Foam FEP

Jacket:
PVDF

Jacket Color:
Black

Compliances:
CMP
RoHS Compliant

Specifications*:

Size: 10 AWG
Number of Conductors: 1
Outside Diameter: 0.405 in
Approx. Weight: 103 lbs / 1000 ft

Belden 9451 Spec SheetView Spec Sheet for Complete Details (PDF)

More Information
Cable TypeCoaxial
Wire Size10 AWG
O.D. (Inches)0.405
