Free shipping on orders over $1000 View Details
$3.50 /ft.

Low Availability

Belden 8458 22 AWG 15 Conductor Multi-Conductor Audio, Control & Instrumentation Cable 300V

Min: 10 ft., Max: 1000 ft. To order multiple lengths, simply enter the desired footage into the quantity fields. Each length will be delivered on its own spool.
Qty:
Qty:
Qty:
Qty:
Qty:
Qty:
Qty:
Qty:
Qty:
Qty:
Add a length

 Free Shipping on all orders over $1000

Belden 8458 22 AWG 15 Conductor Audio, Control & Instrumentation Cable 300V

SKU
BEL8458-FT

Product Details

Learn everything you want to know about this product to make an informed purchase

General Description
Belden 8458 - 22 AWG stranded (7x30) tinned copper conductors, conductors cabled, PVC insulation, PVC Jacket.

Spec Sheet

Belden 8770 Spec SheetView Spec Sheet for Complete Details

Belden 8458 - Specifications
Size:22AWG
Conductors:15
Conductor Material:Tinned Copper
Outside Diameter:.315 inches
Jacket Color:Chrome
Jacket Material:PVC (Polyvinyl Chloride)



More Information
Wire Size22 AWG
# of Conductors15 Conductors
O.D. (Inches)0.315
Ampacity2.1
ManufactureBelden
