Alpha V16008, 8/4C, in.dustrial Series V, Foil/Braid Shielded, VFD Control Cable, 600/1000V

Alpha V16008, 8/4C, Industrial Series V, Foil/Braid Shielded, VFD Control Cable, 600/1000V

Description:
Optimized specifically for variable-frequency drives, Alpha Wire's Series V VFD cable offers industry-leading mechanical and electrical performance.

Jacket Color:
Black

Conductor Color Coding:

Applications:
• Medium-to high-flex equipment
• Factory equipment interconnects
• Robotics
• Machine tools
• Automotive assembly equipment
• Conveyor systems
• Control panels
• Solar farms
• Transfer shuttles
• Automated pick-and-place systems
• PLC-controlled equipment
• Automated handling systems
• Control/monitoring of speed and position

Operating Temperature:

-40°C to +90°C

Compliances:
CA Prop 65
UL RHW-2
UL XHHW-2
UL TC-ER
UL 1000V Flexible Motor Supply Cable
ROHS Compliant
CSA AWM I/II A/B FT4
CE LVD 73/23/EEC Amend. 93/68/EEC
Pennsylvania MHSA

Alpha V160008 Specifications:
Size: 8 AWG
Number of Conductors: 3 + 1 Ground
Conductor Strand: 133/29
Conductor: Stranded Tinned Copper
Jacket Thickness: 0.065 inches
Jacket: Black PVC
Insulation Thickness: 0.061 inches
Insulation: Cross-Linked polyethylene
Outside Diameter: 0.920 inches
Weight: 0.425 lbs per/ft
Voltage: 600/1000V

Spec Sheet:

View Spec Sheet for Complete Details
