Alpha F221B3/8 - Flame Retardant Heat Shrink Tubing, Irradiated Polyolefin, 0.375 Inch, 2 to 1 Shrink Ratio
Alpha F221B3/8 - Flame Retardant Heat Shrink Tubing, Irradiated Polyolefin, 0.375 Inch, 2 to 1 Shrink Ratio
Product Details
Learn everything you want to know about this product to make an informed purchaseAlpha F221B3/8 - Flame Retardant Heat Shrink Tubing, Irradiated Polyolefin, 0.375 Inch, 2 to 1 Shrink Ratio
Description
Our FIT heat-shrink tubing offers a reliable way to protect and seal terminations or add additional mechanical ruggedness. FIT preferred heatshrink products are made from premium compounds under the tightest manufacturing controls. This means FIT will consistently have excellent physical characteristics such as low longitudinal shrinkage and wide temperature ranges while providing an elegant appearance when used alone or on OEM equipment.
Wall Thickness: 0.025 Inch
Diameter Before Shrink: 0.375 Inch
Diameter After Shrink: 0.187 Inch
Weight: 0.04 lbs/ft
Color: Black (Call for other Colors)
Features and Benefits:
• Flame retardant
• Cross-linked polyolefin (Tubing Material)
• Excellent general-purpose tubing
• Low water absorption
• UV resistant (black only)
• Operating Temperature -55°C to +135°C, -55°C to +125°C (UL,CSA)
• Shrink Temperature 90°C min, 121°C full recovery
Standards
• UL 224 (except clear)
• CSA 198 (except clear)
• CA Prop 65
• RoHS Compliant
• Reach
• AMS-DTL-23053/5 Class 1 (except clear)
• AMS-DTL-23053/5 Class 2 (clear)
View Spec Sheet for Complete Details
Stocked | Yes |
---|
