Alpha F2213/4 - Flame Retardant Heat Shrink Tubing, Irradiated Polyolefin/ Cross-linked Polyolefin, 0.750 Inch, 2 to 1 Shrink Ratio

Min: 1 ft., Max: 10000 ft. To order multiple lengths, simply enter the desired footage into the quantity fields. Each length will be delivered on its own spool.
Add a length

 Free Shipping on all orders over $1000

Alpha F2213/4 - Flame Retardant Heat Shrink Tubing, Irradiated Polyolefin, 0.750 Inch, 2 to 1 Shrink Ratio

SKU
AWF2213/4

Product Details

Learn everything you want to know about this product to make an informed purchase

***SHIPS WITHIN 3-4 BUSINESS DAYS FROM THE FACTORY***

Alpha F2213/4 - Flame Retardant Irradiated Cross-linked Polyolefin, Heat Shrink Tubing, 0.750 Inch, 2 to 1 Shrink Ratio

Description
Our FIT heat-shrink tubing offers a reliable way to protect and seal terminations or add additional mechanical ruggedness. FIT preferred heatshrink products are made from premium compounds under the tightest manufacturing controls. This means FIT will consistently have excellent physical characteristics such as low longitudinal shrinkage and wide temperature ranges while providing an elegant appearance when used alone or on OEM equipment.


Wall Thickness:  0.030 Inch
Diameter Before Shrink:  0.750 Inch
Diameter After Shrink:  0.375 Inch
Weight: 0.06 lbs/ft
Color:  Red (Call for other Colors)


Features and Benefits:
• Low Shrink Temperature
• Flame retardant
• Fast recovery time
• Excellent general-purpose tubing

• Low water absorption
• UV resistant (black only)
• Operating Temperature  -55°C to +135°C,  -55°C to +125°C (UL,CSA)
• Shrink Temperature 90°C min, 121°C full recovery



Standards
• UL 224 (except clear)
• CSA 198 (except clear)
• CA Prop 65
• RoHS Compliant
• Reach
• AMS-DTL-23053/5 Class 1 (except clear)
• AMS-DTL-23053/5 Class 2 (clear)


Belden 9451 Spec SheetView Spec Sheet for Complete Details
