Alpha F22111/2 - Flame Retardant Heat Shrink Tubing, Irradiated Polyolefin/ Cross-linked Polyolefin, 1.5 Inch, 2 to 1 Shrink Ratio

Min: 1 ft., Max: 10000 ft. To order multiple lengths, simply enter the desired footage into the quantity fields. Each length will be delivered on its own spool.
50 ft.
100 ft.
Black
Add a length

 Free Shipping on all orders over $1000

Alpha F22111/2 - Flame Retardant Heat Shrink Tubing, Irradiated Polyolefin, 1.5 Inch, 2 to 1 Shrink Ratio

SKU
AWF22111/2

Product Details

Learn everything you want to know about this product to make an informed purchase

Alpha F22111/2 - Flame Retardant Irradiated PVC/ Cross-linked Polyolefin, Heat Shrink Tubing, 1.5 Inch, 2 to 1 Shrink Ratio

Description
Our FIT heat-shrink tubing offers a reliable way to protect and seal terminations or add additional mechanical ruggedness. FIT preferred heatshrink products are made from premium compounds under the tightest manufacturing controls. This means FIT will consistently have excellent physical characteristics such as low longitudinal shrinkage and wide temperature ranges while providing an elegant appearance when used alone or on OEM equipment.


Wall Thickness:  0.040 Inch
Diameter Before Shrink:  1.5 Inch
Diameter After Shrink:  0.750 Inch
Weight: 0.018 lbs/ft
Color: (Call for other Colors)

Features and Benefits:
• Flame retardant
• Excellent general-purpose tubing
• Low water absorption
• UV resistant (black only)
• Operating Temperature  -55°C to +135°C,  -55°C to +125°C (UL,CSA)
• Shrink Temperature 90°C min, 121°C full recovery

Standards
• UL 224 (except clear)
• CSA 198 (except clear)
• CA Prop 65
• RoHS Compliant
• Reach
• AMS-DTL-23053/5 Class 1 (except clear)

Belden 9451 Spec SheetView Spec Sheet for Complete Details


                     Have a Question?
 EMAIL US HERE or call 855-880-8010

More Information
StockedYes
