Alpha F2211/4 - Flame Retardant Heat Shrink Tubing, Irradiated Polyolefin, .250 Inch, 2 to 1 Shrink Ratio

Alpha F2211/4 - Flame Retardant Irradiated PVC/ Cross-linked Polyolefin, Heat Shrink Tubing, .250 Inch, 2 to 1 Shrink Ratio

Description
Our FIT heat-shrink tubing offers a reliable way to protect and seal terminations or add additional mechanical ruggedness. FIT preferred heatshrink products are made from premium compounds under the tightest manufacturing controls. This means FIT will consistently have excellent physical characteristics such as low longitudinal shrinkage and wide temperature ranges while providing an elegant appearance when used alone or on OEM equipment.

Wall Thickness:  0.025 Inch
Diameter Before Shrink:  0.250 Inch
Diameter After Shrink:  0.125 Inch
Weight: 0.014 lbs/ft
Color:  (Call for other Colors)

Features and Benefits:
• Low Shrink Temperature
• Flame retardant
• Fast recovery time
• Excellent general-purpose tubing
• Low water absorption
• UV resistant (black only)
• Operating Temperature  -55°C to +135°C,  -55°C to +125°C (UL,CSA)
• Shrink Temperature 90°C min, 121°C full recovery

Standards
• UL 224 (except clear)
• CSA 198 (except clear)
• CA Prop 65
• RoHS Compliant
• Reach
• AMS-DTL-23053/5 Class 1 (except clear)

View Spec Sheet for Complete Details
