Alpha 881807, 18 AWG 7 Conductor, Communication and Control Cable, Unshielded, 300V
Product Details
Learn everything you want to know about this product to make an informed purchaseAlpha 881807, 18 AWG 7 Conductor, Communication and Control Cable, Unshielded, 300V
Color Code:
Black, Red, Green, White, Brown, Blue, Orange
Applications:
Audio systems: speakers, microphones, intercoms
Broadcast and studio
Data transmission: RS-232, 422, 485
CAD/CAM
Computer peripherals
Business machines
Security systems: alarms, cameras, sensors
Control systems
Instrumentation systems
Point-of-sale systems
Banking systems
Features:
Stranded tinned copper conductors
PVC insulation
Slate PVC jacket
Compliances:
CA Prop 65
Reach
UL AWM 2464
UL CL2
CSA AWM I/II A/B FT4
Spec Sheet:
View Spec Sheet for Complete Details (PDF)
Specifications:
Size: 18 AWG
Number of Conductors: 7
Conductor Strand: 16/30
Outside Diameter: 0.302 inches
Insulation Thickness: 0.016 inches
Weight: 0.071 lbs/ft
Voltage: 300 V
| Stocked | Yes |
|---|---|
| Wire Size | 18 AWG |
| # of Conductors | 7 Conductors |
| O.D. (Inches) | 0.302 in. |
| Shielded | No |
