Alpha 79003, 20/4C Unshielded Flexing Control Cable, EcoFlex, 600V

Min: 25 ft., Max: 1000 ft. To order multiple lengths, simply enter the desired footage into the quantity fields. Each length will be delivered on its own spool.
Qty:
Qty:
Qty:
Qty:
Qty:
Qty:
Qty:
Qty:
Qty:
Qty:
Add a length

 Free Shipping on all orders over $1000

Alpha 79003, 20/4C Unshielded Flexin.g Control Cable, EcoFlex, 600V

SKU
AW79003-FT

Product Details

Learn everything you want to know about this product to make an informed purchase

Alpha Wire 79003, 20/4C EcoFlex® Unshielded Flexing Control Cable 600V

Color:
Black, Red, White, Green

Applications:
EcoFlex is the newest innovation in flexing control cables. By combining better performance and minimum environmental impact, EcoFlex uses its mPPE insulation and jacketing to provide all of the advantages in a smaller, lighter flexible control cable.

Features:
Recyclable mPPE jacket and insulation
-40°C to 105°C static, -5°C to 105°C flexing temperature range
RoHS and REACH Compliant
Suitable for use in NFPA 79 applications
Up to 8x Flexing Bend Radius for Shielded cable and 5x for Unshielded cable



Compliances:
UL AWM/STYLE 21819
UL AWM/STYLE 21492
UL VW-1
CSA I A/B FT1
CE
RoHS
REACH
Suitable for use in NFPA 79 applications



Spec Sheet:

Belden 9451 Spec SheetView Spec Sheet for Complete Details (PDF)


Specifications:

Size: 20 AWG
Number of Conductors: 4
Conductor Strand: 10/30
Insulation Thickness: 0.010 inches
Jacket Thickness: 0.035 inches
Outside Diameter: 0.207 inches
Voltage: 600V



More Information
StockedYes
Wire Size20 AWG
# of Conductors4 Conductors
O.D. (Inches)0.207 in.
