Alpha 5022C, 22/2PR Xtra-Guard 1 High Performance Unshielded Cable 300V

Alpha Wire 5022C, 22/2PR Xtra-Guard 1® High Performance Unshielded Cable

Cut to length - Sold by the foot. Enter the desired footage in the QTY box.
Minimum 50' to maximum 1000'. Please call for longer put ups.

Color:
White-Black, White-Brown

Applications:
- Automotive
- Industrial
- Machine Tools
- Marine
- Medical/biotechnology
- Military
- Mining
- Petrochemical
- Semiconductor
- Solar
- Wind Power

Features:
High-performance cable for general-purpose applications
A unique, premium-grade PVC insulation and jacket for easier routing in small spaces
Provides resistance to oils per UL Oil Res I (60C OIL RES) and Class 43
Designed for use in ambient temperatures up to 105 ° C
Temperature range of -35 ° C to + 105 ° C (SR-PVC) and -30 ° C to + 105 ° C (PVC)
Stranded tinned copper conductors
Tinned copper drain wire sized the same as cable conductors
UL SUN RES
Nylon ripcord
Premium PVC jacket

Compliances:
UL AWM 2464
UL CM
VW-1 UL Flame Test
CSA CMG FT4
REACH Compliant
RoHS Compliant

Spec Sheet:

View Spec Sheet for Complete Details (PDF)

Specifications:

Size: 22 AWG
Number of Pairs: 2
Conductor Strand: 7/30
Insulation Thickness: 0.010 inches
Jacket Thickness: 0.032 inches
Outside Diameter: 0.232 inches
Voltage: 300V
