Alpha 45002, 22/2C, Xtra-Guard 4, Extreme Temperature TPE Cable, Unshielded, 300V

Alpha Wire 45002, 22/2C Xtra-Guard® 4 Extreme Temperature TPE Cable, Unshielded 300V

Cut to length - Sold by the foot. Enter the desired footage in the QTY box.
Minimum 50' to maximum 1000'. Please call for longer put ups.

Color Code:
Black, Brown

Applications:
- Wood, paper, pulp, plant operations
- Mining instruments and controls
- Mass transit systems
- Military electronic applications
- Food and beverage plants
- Petrochemical process controls
- Arctic pipeline controls


Features:
High-performance TPE insulation and jacket offering 3x the low-temperature flexibility of conventional PVC
Solvent and water resistant
Fast, easy stripping of insulation and jacket
Color-coded, tinned copper conductors
Outstanding ultraviolet light stability in all jacket colors
Nylon ripcord for easy jacket stripping
Approved by the US Mine Safety and Health Administration and The Pennsylvania Department of Environmental Protection


Compliances:
UL AWM 20237
UL PLTC
CSA AWM I/II A/B FT1
MSHA P-07-KA070017-MSHA
NEC Class 1, Div 2 (22 & 20 AWG)
REACH Compliant
RoHS Compliant
CA Prop 65

Spec Sheet:

View Spec Sheet for Complete Details (PDF)

Specifications:

Size: 22 AWG
Number of Conductors: 2
Conductor Strand: 7/30
Insulation Thickness: 0.016 inches
Jacket Thickness: 0.045 inches
Outside Diameter: 0.218 inches
Weight: 0.014 lbs per ft
Voltage: 300V
