    $0.54 /ft.

    In Stock

    Alpha 2400C, 24/2C, Communication and Control Cable, Foil Shield, 300V

    Min: 50 ft., Max: 1000 ft. To order multiple lengths, simply enter the desired footage into the quantity fields. Each length will be delivered on its own spool.
    Qty:
    Qty:
    Qty:
    Qty:
    Qty:
    Qty:
    Qty:
    Qty:
    Qty:
    Qty:
    Add a length

     Free Shipping on all orders over $1000

    Alpha 2400C, 24/2C, Communication and Control Cable, Foil Shield, 300V

    SKU
    AW2400C-FT
    main product photo

    Product Details

    Learn everything you want to know about this product to make an informed purchase

    Alpha 2400C, 24 AWG 2 Conductors Communication and Control Cable, Foil Shield

    Color:
    Black, White

    Applications:
    Audio systems: speakers, microphones, intercoms
    Broadcast and studio
    Data transmission: RS-232, 422, 485
    CAD/CAM
    Computer peripherals
    Business machines
    Security systems: alarms, cameras, sensors
    Control systems
    Instrumentation systems
    Point-of-sale systems
    Banking systems

    Features:
    Stranded tinned copper conductors
    Pe-Polyethylene insulation
    Aluminum/polyester foil shield, 25% overlap min
    Foil facing outward Stranded tinned copper drain wire
    Slate PVC jacket

    Compliances:
    CA Prop 65
    CSA CMG
    CSA FT4
    UL AWM 2092
    UL VW-1

    Spec Sheet:

    Belden 9451 Spec SheetView Spec Sheet for Complete Details (PDF)


    Specifications:
    Size: 24 AWG
    Number of Conductors: 2
    Conductor Strand: 7/32
    Outside Diameter: 0.156 inches
    Voltage: 300 V



    More Information
    StockedYes
    Wire Size24 AWG
    # of Conductors2 Conductors
    O.D. (Inches)0.156 in.
    ShieldedYes
