    Alpha 1181/50C, 22 AWG 50 Conductor Communication and Control Cable, Unshielded, 300V

    SKU
    AW1181/50C-FT
    main product photo

    Product Details

    Learn everything you want to know about this product to make an informed purchase

    Alpha 1181/50C, 22 AWG 50 Conductor Communication & Control Cable, Unshielded, 300V

    Jacket Color:
    Slate

    Applications:
    Audio systems: speakers, microphones, intercoms
    Broadcast and studio
    Data transmission: RS-232, 422, 485
    CAD/CAM
    Computer peripherals
    Business machines
    Security systems: alarms, cameras, sensors
    Control systems
    Instrumentation systems
    Point-of-sale systems
    Banking systems

    Features:
    Stranded tinned copper conductors
    PVC insulation

    Compliances:
    CA Prop 65
    CSA CMG
    CSA FT4
    UL AWM 2576
    UL CM
    UL VW-1


    Specifications:
    Size: 22 AWG
    Number of Conductors: 50
    Conductor Strand: 7/30
    Jacket Thickness: 0.035 inches
    Outside Diameter: 0.478 inches
    Voltage: 300V

    Spec Sheet:

    Belden 9451 Spec SheetView Spec Sheet for Complete Details

    More Information
    StockedYes
    Wire Size22 AWG
    # of Conductors50 Conductors
    O.D. (Inches)0.478 in.
    ShieldedNo
