Product Details
Learn everything you want to know about this product to make an informed purchaseCut to length - sold by the foot. Enter the desired footage in the QTY box.
Minimum 1' to maximum 1000'. Please call for longer put ups.
Color:
Black.
Applications:
SEOOW Flexible Portable Cord applications include include wiring for industrial machinery, washing machines and various other large appliances, heavy-duty tools, motors, and temporary electrical power and lighting installations for construction sites.
Features:
Excellent resistance to oil and moisture. High flexibility. Excellent abrasion resistance. Water-resistant. Sunlight-resistant. Temperature range: -50ºC to +105ºC
Standards:
MSHA Approved
EPA 40 CFR, Part 26, Subject C, heavy metals per Table 1, TCLP method
Construction:
Conductors:
Fully annealed stranded bare copper per ASTM B-174
Insulation:
TPE
Specifications*:
Size: 4 AWG
Number of Conductors: 4
Conductor Strand: 96/24
Insulation Thickness: 1.22 mm / 0.048 inches
Jacket Thickness: 3.18 mm / 0.125 inches
Outside Diameter: 25.96 mm / 1.022 inches
Weight: 0.775 lbs per ft
Current Amps: 60
Color Code:
4 Conductors: Black, White, Red, Green
*Data provided on this page is subject to change based on different manufacturers variances.
| Stocked | Yes |
|---|---|
| Cable Type | SEOOW - 600V |
| Wire Size | 4 AWG |
| # of Conductors | 4 Conductors |
| Conductor Material | Bare Copper |
| Stranded or Solid | Stranded |
| O.D. (Inches) | 1.022 |
| Ampacity | 60 |
| Voltage | 600V |
| Temp. Rating | -50°C ~ 105°C |
| Insulation Material | TPE - Thermoplastic Elastomer |
| Jacket Material | TPE - Thermoplastic Elastomer |
| Jacket Color | Black |
| Flexibility | High Flexibility |
| Indoor/Outdoor Use | Indoor, Outdoor |
| Features | Weather Resistant, Water Resistant, Oil Resistant |
| Color Code | Black, White, Red, Green |
