24 AWG, 2 Pairs, Computer Cable, Individually Foil Shielded, 500ft or 1000ft Spool

24 AWG, 2 Pairs, Computer Cable, Individually Foil Shielded, 500ft or 1000ft Spool
SKU COMC0910A

$

0.620000

0.620000

/ft
How will you purchase this wire?
0.620000 0.620000
truck FREE SHIPPING ON ORDERS OVER $1000

Please Select Color(s)

Multiple colors can be selected

....

Multiple lengths can be selected

500 1000
Quantity

Select your preferred quantity for each color below. Add additional colors and lengths as needed.

24 AWG, 2 Pairs, Computer Cable, Individually Foil Shielded, 500ft or 1000ft Spool

Grouped product items
Color Length (ft.)
Gray Length 500 ft.
$310.00
Gray Length 1000 ft.
$620.00
truck FREE SHIPPING ON ORDERS OVER $1000
Product Details

Learn everything you want to know about this product to make an informed purchase

Specifications
  • Wire Size

    24 AWG

  • # of Conductors

    4 Conductors

  • # of Pairs

    2 Pair

  • Alt to Belden #

    9729

  • Shielded

    Yes

  • Shield Type

    Individually Foil Shield

Data provided on this page is subject to change based on different manufacturers variances.
See Less
More information

General Cable C0910A, UL 2493, NEC Type CM (UL) c(UL) CMH

Color:
Gray

Applications:
High-speed computers, Control circuits, Industrial equipment, Suitable for low capacitance applications, Suitable for EIA RS-422 CAD/CAM applications, Suggested voltage rating: 300 volts

Compliances:
- NEC Article 800 Type CM/CMH (UL: 75°C, 300V)
- UL Style 2493 (UL: 60°C)
- RoHS Compliant Directive 2002/95/EC
- Designed to meet UL 70,000 BTU Vertical Tray Flame Test


Conductor:
Fully annealed, stranded tinned copper per

Insulation:
Premium-grade, coIor-coded foamed Lo-Cap® polypropylene

Shield:
100% Flexfoil aluminum/polyester, 25% overlap, foil facing in, Stranded tinned copper drain wire

Jacket:
PVC, gray
-20°C to +75°C

Specifications*:

Size: 24 AWG
Number of Conductors: 4
Conductor Stranding: 7/32
Nominal Insulation Thickness: 0.022 inches
Nominal Jacket Thickness: 0.047 inches
Outside Diameter: 0.283 inches
Nominal Cap. pF/ft: A-14.8, B-26.7

Spec Sheet

Belden 9841 Spec SheetView Spec Sheet for Complete Details
