$23.00

In Stock

20 AWG Hookup Wire, UL 1007/1569, 10 Strand, Tinned Copper, 500' or 1000' Spool

Min: 1 ft., Max: 10000 ft. To order multiple lengths, simply enter the desired footage into the quantity fields. Each length will be delivered on its own spool.
500 ft.
1000 ft.
Add a length

 Free Shipping on all orders over $1000

20 AWG Hookup Wire, UL 1007/1569, 10 Strand, Tinned Copper, 500' or 1000' Spool

SKU
UL100720

Product Details

Learn everything you want to know about this product to make an informed purchase

20 AWG Hookup Wire, UL 1007/1569, 10 Strand, Tinned Copper, 500' or 1000' Spool

Applications:
For general purpose internal wiring of electronic and electrical equipment

Standards:
UL 1007/1569
CSA TR-64

Specifications*:

Size: 20 AWG
Number of Strands: 10/30
Conductor Material: Tinned Copper
Insulation Material:  Polyvinyl Chloride (PVC)
Voltage: 300V
Temp: 80°C to 105°C
Insulation Thickness: 0.016 inches
Outside Diameter: 0.070 inches
Weight: 0.0048 lbs per ft



*Data provided on this page is subject to change based on different manufacturers variances.

More Information
Wire Size20 AWG
O.D. (Inches)0.07
