18 AWG Hookup Wire, UL 1007/1569, 16 Strand, Tinned Copper, 500' or 1000' Spool

Min: 1 ft., Max: 10000 ft. To order multiple lengths, simply enter the desired footage into the quantity fields. Each length will be delivered on its own spool.
500 ft.
1000 ft.
Add a length

 Free Shipping on all orders over $1000

18 AWG Hookup Wire, UL 1007/1569, 16 Strand, Tinned Copper, 500' or 1000' Spool

SKU
UL100718

Product Details

Learn everything you want to know about this product to make an informed purchase

***STRIPED COLORS ARE NON-STOCK ITEMS & MAY TAKE 4-5 WEEKS TO SHIP***

18 AWG Hookup Wire, UL 1007/1569, 16 Strand, Tinned Copper, 500' or 1000' Spool

Applications:
For general purpose internal wiring of electronic and electrical equipment

Standards:
UL 1007/1569
CSA TR-64

Specifications*:

Size: 18 AWG
Number of Strands: 16/30
Conductor Material: Tinned Copper
Insulation Material:  Polyvinyl Chloride (PVC)
Voltage: 300V
Temp: 80°C to 105°C
Insulation Thickness: 0.016 inches
Outside Diameter: 0.080 inches
Weight: 0.007 lbs per ft



*Data provided on this page is subject to change based on different manufacturers variances.

More Information
Wire Size18 AWG
O.D. (Inches)0.08
