$380.00

In Stock

Belden 82740 Equal - NEC Type CMP (UL) c(UL)

Min: 1 ft., Max: 10000 ft. To order multiple lengths, simply enter the desired footage into the quantity fields. Each length will be delivered on its own spool.
500 ft. Spool
1000 ft Spool
Add a length

 Free Shipping on all orders over $1000

18 AWG, 1 Pair, Plenum FEP Unshielded Jacket Cable

SKU
BELEQ82740

Product Details

Learn everything you want to know about this product to make an informed purchase

Belden 82740 Equal

A Cost-Effective Alternative to Belden
If you need cable and wire that matches Belden specifications without needing to be Belden brand, we can save you money. Our Belden equivelents are produced under the highest quality standards for extrusion, cabling, twisting, shielding and jacketing -- equivelent to Belden in every way except for the price.

Product Description:
Solid FEP insulated stranded tinned copper conductors with an overall jacket. Shielded version has an aluminum tape and drain wire.

Color:
Red

Applications:
Security Systems
Intercom Systems
Sound/Audio System
Power-Limited Controls
Suggested voltage rating: 300 volts

Compliances:
RoHS Compliant Cables are manufactured to meet current NEC guidelines and are verifed by outside standards organizations including c(UL)us and c(ETL)us.

Conductor:
18 AWG Stranded Tinned Copper Twisted Pair

Insulation:
Solid FEP

Specifications:

Size: 18 AWG
Number of Pairs: 1
Conductor Stranding: 19
Nominal Jacket Thickness: 0.015 inches
Outside Diameter: 0.158 inches






More Information
StockedYes
Wire Size18 AWG
# of Conductors2 Conductors
# of Pairs1 Pair
O.D. (Inches)0.158
Alt to Belden #82740
ShieldedNo
Shield TypeUnshielded
