14/5 SJTOW White Portable Cord 300V UL/CSA

SKU SJT14s5W

$

2.030000

2.030000

/ft
How will you purchase this wire?
2.030000 2.030000
truck FREE SHIPPING ON ORDERS OVER $1000
MIN: 1 FT. | MAX: 10000 FT. 1 10000 tooltip To order multiple lengths, simply enter the desired footage into the quantity fields. Each length will be delivered on its own spool.

Please Select Color(s)

Multiple colors can be selected

....
Quantity

Select your preferred quantity for each color below. Add additional colors and lengths as needed.

14/5 SJTOW White Portable Cord 300V UL/CSA

Color Length (ft.) Price
White

Length (ft.)

$2.03
add Add a length
Grouped product items
Color Length (ft.)
White Length 500 ft.
$1,015.00
truck FREE SHIPPING ON ORDERS OVER $1000
Product Details

Learn everything you want to know about this product to make an informed purchase

Specifications
  • Wire Size

    14 AWG

  • # of Conductors

    5 Conductors

  • O.D. (Inches)

    0.47

  • Ampacity

    12

Data provided on this page is subject to change based on different manufacturers variances.
See Less
More information

Cut to length - sold by the foot. Enter the desired footage in the QTY box.
Minimum 1' to maximum 2000'. Please call for longer put ups.

Color:
White

Applications:
14/5 SJTOW Flexible Cord applications include portable tools, motors, floor maintenance equipment, hospital equipment, sound equipment, washing machines, portable lights, lamps and similar equipment.

Jacket:
Polyvinylchloride (PVC). Temperature range: -40ºC to +105ºC. Voltage rating: 300 Volts.

Features:
Oil resistant jacket. Resists: Oils, Acids, Alkalies, Ozone

Standards:
UL Flexible Cord - UL Subject 62
MSHA Approved (where applicable)

Construction:
Conductors:
18 through 10 AWG fully annealed stranded bare copper per ASTM B-174
Insulation:
Premium-grade, color-coded PVC.

Specifications*:

Size: 14 AWG
Number of Conductors: 5
Conductor Strand: 41/30
Insulation Thickness: 0.762 mm / 0.030 inches
Outside Diameter: 11.938 mm / 0.470 inches
Weight: 0.140 lbs per ft
Current Amps: 12 (Green conductor for grounding only)

Color Code:
5 Conductors: Black, White, Green, Red, Orange

*Data provided on this page is subject to change based on different manufacturers variances.
