14-37C w/ Ground Type MC Cable, PVC Jacket, Interlocked Armor Control Cable

SKU MCIA1437C
How will you purchase this wire?
10.820000 10.820000
truck FREE SHIPPING ON ORDERS OVER $1000
MIN: 1 FT. | MAX: 10000 FT. 1 10000 tooltip To order multiple lengths, simply enter the desired footage into the quantity fields. Each length will be delivered on its own spool.

Please Select Color(s)

Multiple colors can be selected

....
Quantity

Select your preferred quantity for each color below. Add additional colors and lengths as needed.

14-37C w/ Ground Type MC Cable, PVC Jacket, Interlocked Armor Control Cable

Color Length (ft.) Price
Black

Length (ft.)

add Add a length
Grouped product items
Color Length (ft.)
Black Length 500 ft.
truck FREE SHIPPING ON ORDERS OVER $1000
Product Details

Learn everything you want to know about this product to make an informed purchase

Specifications
  • Wire Size

    14 AWG

  • # of Conductors

    37 Conductors w/ Ground

  • O.D. (Inches)

    1.32

Data provided on this page is subject to change based on different manufacturers variances.
See Less
More information

14-37C w/ Ground Type MC Cable w/ PVC Jacket
600 Volt UL Type MC, CT USE, 90°C
XLP VW-1 XHHW-2 Insulation
Aluminum Armor
Copper Conductors

Cut to length - sold by the foot. Enter the desired footage in the QTY box.
Minimum 50' to maximum 2500'. Please call for longer put ups.

Color:
Black

Applications:
For use in harsh environments where maximum conductor protection is required. Used for power, control and lighting circuits in a broad range of commercial and industrial pulp and paper, mining, and petroleum applications. Approved for use in wet or dry locations at 90°C, for installation indoors or outdoors, aerially, in conduits, ducts, cable trays or direct burial in circuits not exceeding 600 volts. May be used in NEC Class I and II, Division 2 and Class III, Division 1 and 2 hazardous locations. UL approved for use at 90°C for continuous operation, 130°C for emergency overload conditions, and 250°C for short circuit conditions. Aluminum interlocked armor cable is recommended as an economical alternative to wire in conduit systems.

Conductor:
Soft bare annealed copper per ASTM B-3, Class B stranding per ASTM B-8

Insulation:
Cross-linked polyethylene (XLP) per UL Standard 44 for Type XHHW-2, VW-1 conductors

Jacket:
Black sunlight-resistant PVC per UL Standard 1569

Grounding Conductor:
Soft bare annealed copper per ASTM B-3, Class B stranding per ASTM B-8 sized in accordance with UL Standard 1569

Armor:
Aluminum interlocked tape armor per UL Standard 1569, also available in galvanized steel armor

Flame Tests:
UL 1581 (70,000 BTU/hr) Flame Test

Color Code:
ICEA Method 1, Table E-2

Connectors:
• Explosion Proof, Class 1 Division 2: 424CU series – aluminum exterior components, nickel-plated brass interior components
• Rain Tight: 416MC series – all nickel-plated brass

Specifications*:

Size: 14 AWG
Number of Conductors: 37
Ground Wire Size: 14 AWG
Minimum AVG Insulation Thickness: 0.030 inches
Minimum AVG Jacket Thickness: 0.050 inches
Armor Diameter: 1.21 inches
Overall Diameter: 1.32 inches
Net Weight: 1.20 lbs per ft
Class 1 Div. 2 Connector Number: 424CU06
Rain Tight Connector Number: 416MC06



*Data provided on this page is subject to change based on different manufacturers variances.
