14-2C Stranded Traffic Signal Cable IMSA 50-2, 600V

SKU IMSA5014s2STR

$

0.650000

0.650000

/ft
How will you purchase this wire?
0.650000 0.650000
truck FREE SHIPPING ON ORDERS OVER $1000
MIN: 1 FT. | MAX: 10000 FT. 1 10000 tooltip To order multiple lengths, simply enter the desired footage into the quantity fields. Each length will be delivered on its own spool.

Please Select Color(s)

Multiple colors can be selected

....
Quantity

Select your preferred quantity for each color below. Add additional colors and lengths as needed.

14-2C Stranded Traffic Signal Cable IMSA 50-2, 600V

Color Length (ft.) Price
Black

Length (ft.)

$0.65
add Add a length
Grouped product items
Color Length (ft.)
Black Length 500 ft.
$325.00
truck FREE SHIPPING ON ORDERS OVER $1000
Product Details

Learn everything you want to know about this product to make an informed purchase

Specifications
  • Wire Size

    14 AWG

  • # of Conductors

    2 Conductors

  • O.D. (Inches)

    0.35

Data provided on this page is subject to change based on different manufacturers variances.
See Less
More information

14-2C Stranded Traffic Signal Cable IMSA 50-2, 600V

Cut to length - sold by the foot. Enter the desired footage in the QTY box.
Minimum 100' to maximum 1000'. Please call for longer put ups.

Color:
Black

Applications:
For use in traffic signal installations, suitable for conduit installations in wet or dry locations.

Description:
 2 conductor tinned copper wires conforming to ASTM B-3 before insulating, Insulated with polyethylene (per UL 62, ASNI C33.1 - except for the cold bend test shall be minus 55ºC). Twisted together with an overall aluminum mylar shielding tape around the conductors with the drain wire outside the tape. Jacketed with a high quality sunlight resistant polyethylene compound. Rated at 600V

Conductor:
Stranded Tinned Copper per ASTM B-3

Insulation:
PE-Polyethylene

Jacket:
PE-Polyethylene

Color Code:
Black, Clear

Specifications*:

Size: 14 AWG
Number of Conductors: 2
Conductor Strand:  19
Outer Jacket Thickness: 0.045 inches
Outside Diameter:  0.340 inches
Voltage:  600V
Temp Rating:  75 C
Weight: 0.056 lbs per ft



*Data provided on this page is subject to change based on different manufacturers variances.
