14-1C Stranded Traffic Signal Cable IMSA 51-7, 600V

SKU
IMSA5114s1STR-FT

Product Details

Learn everything you want to know about this product to make an informed purchase

14 AWG 1 Conductor Stranded Traffic Signal Cable IMSA 51-7, 600V

Cut to length - sold by the foot. Enter the desired footage in the QTY box.

Minimum 100' to maximum 1000'. Please call for longer put ups.

Color:
Black

Applications:
Signal heads & pedestrian crossing.

Description:
1 conductor, 19 strand copper wire , conforming to ASTM B-3 before insulating. Insulated with Cross-Link Polyethylene & loosely encased in a PVC or Polyethylene tube. Rated at 600V

Conductor:
Stranded Bare Copper per ASTM B-3

Insulation:
PE-Polyethylene

Jacket:
PVC - Polyvinyl Chloride

Color Code:
Black

Specifications*:

Size: 14 AWG
Number of Conductors: 1
Conductor Strand: Stranded
Outer Jacket Thickness: 0.030 inches
Outside Diameter:  0.250 inches
Voltage:  600V
Temp Rating:  75 C

More Information
Wire Size14 AWG
# of Conductors1 Conductor
O.D. (Inches)0.250
