1 AWG 3C Type W Portable Power Cable

SKU TWC13C
How will you purchase this wire?
19.760000 19.760000
truck FREE SHIPPING ON ORDERS OVER $1000
MIN: 1 FT. | MAX: 10000 FT. 1 10000 tooltip To order multiple lengths, simply enter the desired footage into the quantity fields. Each length will be delivered on its own spool.

Please Select Color(s)

Multiple colors can be selected

....
Quantity

Select your preferred quantity for each color below. Add additional colors and lengths as needed.

1 AWG 3C Type W Portable Power Cable

Color Length (ft.) Price
Black

Length (ft.)

add Add a length
Grouped product items
Color Length (ft.)
Black Length 500 ft.
truck FREE SHIPPING ON ORDERS OVER $1000
Product Details

Learn everything you want to know about this product to make an informed purchase

Specifications
  • Jacket Color

    Black

  • Wire Size

    1 AWG

  • # of Conductors

    3 Conductors

  • O.D. (Inches)

    1.475

  • Ampacity

    177

Data provided on this page is subject to change based on different manufacturers variances.
See Less
More information

2000V, 90°C (-40°C), Oil and Sunlight Resistant.

Cut to length - sold by the foot. Enter the desired footage in the QTY box.
Minimum 10' to maximum 1000'. Please call for longer put ups.

Color:
Black

Applications:
Type W Portable Power Cable is suitable for use in industrial and light-to-medium mining applications, heavy-duty service, temporary power supply cables, motor, battery and generator leads. Also suitable for mobile and portable electrical equipment.

Compliances:
- UL Listed - Type W per UL 1650
- Conductors are manufactured in accordance with ASTM and B-172
- Made in accordance with ICEA S-75-381
- NEMA WC-58 - Portable and Power Feeder Cables for Use in Mines and Similar Locations
- MSHA accepted, P-136-135, LR65300
- CSA or c(UL) Certified as applicable
- RoHS Compliant
- Meets FT-5 Flame Test

Conductor:
Fully annealed stranded bare copper per ASTM B-172.

Insulation:
EP rubber insulation

Jacket:
CPE rubber jacket. Jackets are reinforced by a braid or serve of synthetic material.

Specifications*:

Size: 1 AWG
Number of Conductors: 3
Conductor Strand: 210
Nominal Insulation Thickness: 0.080 inches / 2.03 mm
Outside Diameter: 1.475 inches / 37.47 mm
Current AMPS: 177
Net Weight: 1.81 lbs per ft

*Data provided on this page is subject to change based on different manufacturers variances.
