Alpha 78042, 20/2C Unshielded Mini Communication Cable, EcoCable

SKU AW78042
How will you purchase this wire?
2.110000 2.110000
truck FREE SHIPPING ON ORDERS OVER $1000

Please Select Color(s)

Multiple colors can be selected

....

Multiple lengths can be selected

100
Quantity

Select your preferred quantity for each color below. Add additional colors and lengths as needed.

Alpha 78042, 20/2C Unshielded Mini Communication Cable, EcoCable

Grouped product items
Color Length (ft.)
N/A Length 100 ft.
truck FREE SHIPPING ON ORDERS OVER $1000
Product Details

Learn everything you want to know about this product to make an informed purchase

Specifications
  • Wire Size

    20 AWG

  • # of Conductors

    2 Conductors

  • O.D. (Inches)

    0.142 in.

Data provided on this page is subject to change based on different manufacturers variances.
See Less
More information

Alpha 78042, 20/2C Unshielded Mini Communication Cable, EcoCable

Color:
Gray

Applications:
Alpha’s EcoGen™ family of wire and cable combines better performance with minimum environmental impact. Each member of the EcoGen™ family derives its advantages from modified polyphenylene ether (mPPE) jacketing and insulation.

Features:
Up to 32% smaller than PVC
Up to 44% lighter than PVC
92% lower outgassing than PVC
100% recyclable mPPE insulation and jacketing
Contains no halogens, phthalates, or heavy metals
Multiconductor or multipair
Unshielded

Compliances:
UL AWM 21460
UL VW-1
CSA I A/B FT1
CE
RoHS
REACH
WEEE
Suitable for use in NFPA 79 applications
ISO 10993-5

Spec Sheet:

Belden 9451 Spec SheetView Spec Sheet for Complete Details (PDF)


Specifications:

Size: 20 AWG
Number of Conductors: 2
Conductor Strand: 19/32
Insulation Thickness: 0.007 inches
Jacket Thickness: 0.015 inches
Outside Diameter: 0.142 inches
Voltage: 300V
