Alpha 77126, 18/3C Recyclable Control Cable, Foil Shield, EcoCable, Halogen Free, 600V

Alpha Wire 77126, 18 AWG 3 Conductor, Recyclable Control Cable, 16/30 Stranding EcoCable® Halogen Free, 600V

Color:
Black, Brown, Red

Applications:
EcoCable is the next generation of control cables. By combining better performance and minimum environmental impact, EcoCable uses its mPPE insulation and jacketing to provide all of the advantages in a smaller, lighter control cable.

Features:
Up to 47% smaller than PVC
Up to 65% lighter than PVC
Up to 87% lower outgassing
Zero Halogen
Capable of handling extreme temperatures
100% recyclable

Compliances:

UL AWM/STYLE 11231
UL AWM/STYLE 21915
CSA AWM I/II A/B FT2
CE compliant
RoHS
REACH

Spec Sheet:

View Spec Sheet for Complete Details (PDF)

Specifications:

Size: 18 AWG
Number of Conductors: 3
Conductor Strand: 16/30
Insulation Thickness: 0.010 inches
Outside Diameter: 0.217 inches
Voltage: 600V
Jacket Color: Slate
