Alpha 6622, 24/2C Communication and Control Cable, IRRPVC Unshielded, 600V

Min: 50 ft., Max: 1000 ft. To order multiple lengths, simply enter the desired footage into the quantity fields. Each length will be delivered on its own spool.
Qty:
Qty:
Qty:
Qty:
Qty:
Qty:
Qty:
Qty:
Qty:
Qty:
Add a length

 Free Shipping on all orders over $1000

Alpha 6622, 24/2C Communication and Control Cable, MIL-W-16878B, Unshielded, 600V

SKU
AW6622-FT

Product Details

Learn everything you want to know about this product to make an informed purchase

Alpha 6622, 24 AWG 2 Conductor Communication and Control Cable, Irradiated PVC insulation Unshielded, 600V

Jacket Color:

White

Color Coding:
White, Black

Applications:
Audio systems: speakers, microphones, intercoms
Broadcast and studio
Data transmission: RS-232, 422, 485
CAD/CAM
Computer peripherals
Business machines
Security systems: alarms, cameras, sensors
Control systems
Instrumentation systems
Point-of-sale systems
Banking systems

Features:
Stranded tinned copper conductors
Irradiated PVC insulation
Clear polyester wrap
White PVC Jacket

Compliances:
CA Prop 65
UL AWM 2576 (150V) VW-1
MIL-W-16878/Type B
Reach



Specifications:

Size: 24 AWG
Number of Conductors: 2
Conductor Strand: 7/32
Jacket Thickness: 0.032 inches
Outside Diameter: 0.155 inches
Voltage: 600V

Spec Sheet:

Belden 9451 Spec SheetView Spec Sheet for Complete Details

More Information
Wire Size24 AWG
# of Conductors2 Conductors
O.D. (Inches)0.155 in.
