8 Gauge Marine Wire, Tinned Copper, UL 1426

SKU MGBC8

$

0.893000

0.893000

/ft
How will you purchase this wire?
0.893000 0.893000
truck FREE SHIPPING ON ORDERS OVER $1000

Please Select Color(s)

Multiple colors can be selected

.... ....

Multiple lengths can be selected

100 500 1000
Quantity

Select your preferred quantity for each color below. Add additional colors and lengths as needed.

8 Gauge Marine Wire, Tinned Copper, UL 1426

Grouped product items
Color Length (ft.)
Black Length 100 ft.
$89.30
Red Length 100 ft.
$89.30
Black Length 500 ft.
$446.50
Red Length 500 ft.
$446.50
Black Length 1000 ft.
$893.00
Red Length 1000 ft.
$893.00
truck FREE SHIPPING ON ORDERS OVER $1000
Product Details

Learn everything you want to know about this product to make an informed purchase

Specifications
  • Wire Size

    8 AWG

  • # of Conductors

    1 Conductor

  • O.D. (Inches)

    0.27

Data provided on this page is subject to change based on different manufacturers variances.
See Less
More information

***SHIPS WITHIN 2-3 WEEKS***

Marine Grade, 8 Gauge Marine Wire (Boat Cable), Tinned Copper Stranding, UL 1426.  100ft or 500ft Spool

Applications:
UL Listed, single-conductor tinned wire ideal for use in the high corrosive environment of marine applications. Special electro-tinned, copper strands also increase protection against corrosion for recreational vehicles, automotive, trucks, and trailers. Tinned copper stranding is extremely flexible for easy routing through marine applications and easier to solder than bare copper. Flame retardant, PVC insulation is highly resistant to water, oil, grease, gasoline, and other damaging solvents. High voltage tolerance of up to 600 volts adds to versatility to its use in multiple marine and other suitable applications.

Standards: Meets DOT and Coast Guard specs for electrical systems

Specifications*:

Size: 8 Gauge
Number of Strands: 7 x 24/30
Voltage: 600Volts
Temp: Rated at 105°C (221°F) dry and 75°C (167°F) wet
Jacket Material: Polyvinylchloride (PVC)
Outside Diameter: 0.270 inches
Weight: 0.08 lbs per ft.

*Data provided on this page is subject to change based on different manufacturers variances.
