6 AWG Flexible Welding Cable - 600V. Cut to length and sold by the Foot.
Product Details
Learn everything you want to know about this product to make an informed purchase#6 Welding Cable Class K
Cut to length - Sold by the foot
Minimum 1' to maximum 5000'. Please call for longer put ups.
Colors Available:
Black, Red, Green, Yellow
Applications:
Secondary voltage resistance welding leads. Power supply applications not exceeding 600 volts AC.
Also Known As:
Battery Cable, 6 Gauge Welding Lead, Temporary Power Cable, 6 Gauge Flexible Cable, 600 Volt Cable, #6 Copper Cable, 6 Gauge Welders Lead, Hurricane Cable, 250ft roll of Welding Cable, 500ft roll of Welding Cable or 1000ft Welding Cable
Features:
Good flexibility. Abrasion-resistant. Good color retention.
Jacket:
Premium-grade 90ºC EPDM, black or red. Temperature range: -40ºC to +90ºC
Standards:
RoHS Compliant
Conductor:
Fully annealed stranded bare copper Class K
Specifications*:
Size: 6 AWG
Conductor Strand: 259/30
Outside Diameter: 9.65 mm / 0.380 inches
Weight: 0.142 lbs per ft
Current Amps: 75 (For 600 Volt In-Line Applications)
*Data provided on this page is subject to change based on different manufacturers variances.
| Stocked | Yes |
|---|---|
| Wire Size | 6 AWG |
| # of Conductors | 1 Conductor |
| O.D. (Inches) | 0.38 |
| Ampacity | 75 |
