22 AWG Irradiated PVC Hookup Wire, UL 1429, 7 Strand, Tinned Copper, 500' or 1000' Spool

SKU UL1429227

$

0.084600

0.084600

/ft
How will you purchase this wire?
0.084600 0.084600
truck FREE SHIPPING ON ORDERS OVER $1000

Please Select Color(s)

Multiple colors can be selected

.... .... .... .... ....

Multiple lengths can be selected

500 1000
Quantity

Select your preferred quantity for each color below. Add additional colors and lengths as needed.

22 AWG Irradiated PVC Hookup Wire, UL 1429, 7 Strand, Tinned Copper, 500' or 1000' Spool

Grouped product items
Color Length (ft.)
Black Length 500 ft.
$42.30
White Length 500 ft.
$42.30
Red Length 500 ft.
$42.30
Blue Length 500 ft.
$42.30
Violet Length 500 ft.
$42.30
Black Length 1000 ft.
$84.60
White Length 1000 ft.
$84.60
Red Length 1000 ft.
$84.60
Blue Length 1000 ft.
$84.60
Violet Length 1000 ft.
$84.60
truck FREE SHIPPING ON ORDERS OVER $1000
Product Details

Learn everything you want to know about this product to make an informed purchase

Specifications
  • Wire Size

    22 AWG

  • O.D. (Inches)

    0.052 in.

Data provided on this page is subject to change based on different manufacturers variances.
See Less
More information

22 AWG Irradiated PVC Hookup Wire, UL 1429, 7 Strand, Tinned Copper, 500' or 1000' Spool

Applications:
Internal wiring of appliances, electronic & test equipment, computers & business machines.

Standards:
Complies with MIL-Spec 16878/1
UL recognized AWM Style 1429 per UL 758 requirements
CSA AWM

Specifications*:

Size: 22 AWG
Number of Strands: 7
Conductor Material: Tinned Copper
Insulation Material: Polyvinyl Chloride (PVC) (Irradiated)
Voltage: 150V
Temp: -55°C to 105°C (UL/CSA 80°C)
Conductor Diameter: 0.032 inches
Outside Diameter: 0.052 inches
Weight: 0.039 lbs per ft

*Data provided on this page is subject to change based on different manufacturers variances.
