22 AWG Hookup Wire, UL 1007/1569, 7 Strand, Tinned Copper, 500' or 1000' Spool

SKU UL100722

$

0.050000

0.050000

/ft
How will you purchase this wire?
0.050000 0.050000
truck FREE SHIPPING ON ORDERS OVER $1000

Please Select Color(s)

Multiple colors can be selected

.... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... ....

Multiple lengths can be selected

500 1000
Quantity

Select your preferred quantity for each color below. Add additional colors and lengths as needed.

22 AWG Hookup Wire, UL 1007/1569, 7 Strand, Tinned Copper, 500' or 1000' Spool

Grouped product items
Color Length (ft.)
Black Length 500 ft.
$25.00
Green Length 500 ft.
$25.00
White Length 500 ft.
$25.00
Red Length 500 ft.
$25.00
Orange Length 500 ft.
$25.00
Yellow Length 500 ft.
$25.00
Blue Length 500 ft.
$25.00
Brown Length 500 ft.
$25.00
Gray Length 500 ft.
$25.00
Violet Length 500 ft.
$25.00
Pink Length 500 ft.
$25.00
Black Length 1000 ft.
$50.00
Green Length 1000 ft.
$50.00
White Length 1000 ft.
$50.00
Red Length 1000 ft.
$50.00
Orange Length 1000 ft.
$50.00
Yellow Length 1000 ft.
$50.00
Blue Length 1000 ft.
$50.00
Brown Length 1000 ft.
$50.00
Gray Length 1000 ft.
$50.00
Violet Length 1000 ft.
$50.00
Pink Length 1000 ft.
$50.00
White w/ Blue Stripe Length 1000 ft.
$62.00
White w/ Orange Stripe Length 1000 ft.
$62.00
White w/ Red Stripe Length 1000 ft.
$62.00
Black w/ White Stripe Length 1000 ft.
$62.00
Brown w/ White Stripe Length 1000 ft.
$62.00
Red w/ White Stripe Length 1000 ft.
$62.00
Red w/ Black Stripe Length 1000 ft.
$62.00
Orange w/ Black Stripe Length 1000 ft.
$62.00
Yellow w/ Black Stripe Length 1000 ft.
$62.00
Green w/ White Stripe Length 1000 ft.
$62.00
Blue w/ White Stripe Length 1000 ft.
$62.00
Purple w/ White Stripe Length 1000 ft.
$62.00
Gray w/ Black Stripe Length 1000 ft.
$62.00
White w/ Black Stripe Length 1000 ft.
$62.00
truck FREE SHIPPING ON ORDERS OVER $1000
Product Details

Learn everything you want to know about this product to make an informed purchase

Specifications
  • Wire Size

    22 AWG

  • O.D. (Inches)

    0.062

Data provided on this page is subject to change based on different manufacturers variances.
See Less
More information

***STRIPED COLORS ARE NON-STOCK ITEMS & MAY TAKE 4-5 WEEKS TO SHIP***

1000 FT Min for Stripe


22 AWG Hookup Wire, UL 1007/1569, 7 Strand, Tinned Copper, 500' or 1000' Spool

Applications:
For general purpose internal wiring of electronic and electrical equipment

Standards:
UL 1007/1569
CSA TR-64

Specifications*:

Size: 22 AWG
Number of Strands: 7/30
Conductor Material: Tinned Copper
Insulation Material:  Polyvinyl Chloride (PVC)
Voltage: 300V
Temp: 80°C to 105°C
Insulation Thickness: 0.016 inches
Outside Diameter: 0.062 inches
Weight: 0.0037 lbs per ft



*Data provided on this page is subject to change based on different manufacturers variances.
