14 AWG Switchboard Wire, Type SIS, 41 Strand, Tinned Copper, 100ft, 250ft, 500ft or 1000ft





Min: 1 ft., Max: 10000 ft. To order multiple lengths, simply enter the desired footage into the quantity fields. Each length will be delivered on its own spool.
100 ft.
250 ft.
500 ft
1000 ft
Add a length

 Free Shipping on all orders over $1000

14 AWG Switchboard Wire Type SIS, 41 Strand, Tinned Copper, 100ft, 250ft, 500ft or 1000ft

SKU
SIS14

Product Details

Learn everything you want to know about this product to make an informed purchase

14 AWG Switchboard Wire, Type SIS, 41 Strand, Tinned Copper, 100ft, 250ft, 500ft or 1000ft

Applications:
Switchboard Wire is for use in switchboards for control and power circuits, for applications up to 90°C and 600 volts. 12 gauge and larger are approved for us by the power switchgear assemblies.

Conductors:
Switchboard Wire has a stranded soft drawn tinned coated copper conductor per ASTM B33, B174.

Insulation:
Switchboard Wire has cross-linked polyethylene insulation. Switchboard Wire is available in several insulation colors.

Standards:
NEMA SG 5-1975
UL 3320
NEC Article


Specifications*:

Size: 14 AWG
Number of Strands: 41
Temp: 90°C
Insulation Thickness: 0.030 inches
Outside Diameter: 0.13 inches

*Data provided on this page is subject to change based on different manufacturers variances.

More Information
StockedYes
Wire Size14 AWG
# of Conductors1 Conductor
O.D. (Inches)0.13
