SJTO Flexible Portable Cord. Cut to length - sold by the Foot.

Min: 25 ft., Max: 10000 ft. To order multiple lengths, simply enter the desired footage into the quantity fields. Each length will be delivered on its own spool.
Qty:
Qty:
Qty:
Qty:
Qty:
Qty:
Qty:
Qty:
Qty:
Qty:
Add a length

 Free Shipping on all orders over $1000

14/5 SJTO Portable Cord 300v UL/CSA

SKU
SJT14s5-FT

Product Details

Learn everything you want to know about this product to make an informed purchase

Cut to length - sold by the foot. Enter the desired footage in the QTY box.

Minimum 15' to maximum 2000'. Please call for longer put ups.

Color:
Black

Applications:
SJTO Flexible Cord applications include portable tools, motors, floor maintenance equipment, hospital equipment, sound equipment, washing machines, portable lights, lamps and similar equipment.

Jacket:
Polyvinylchloride (PVC), Gray or Yellow. Temperature range: -20ºC to +60ºC. Voltage rating: 300 Volts.

Features:
Oil resistant jacket. Resists: Oils, Acids, Alkalies, Ozone

Standards:
UL Flexible Cord - UL Subject 62
MSHA Approved (where applicable)

Construction:
Conductors:
18 through 6 AWG fully annealed stranded bare copper per ASTM B-174
Insulation:
Premium-grade, color-coded PVC.

Specifications*:

Size: 14 AWG
Number of Conductors: 5
Conductor Strand: 41/30
Insulation Thickness: 0.762 mm / 0.030 inches
Jacket Thickness: 1.143 mm / 0.045 inches
Outside Diameter: 11.938 mm / 0.470 inches
Weight: 0.140 lbs per ft
Current Amps: 12 (Green conductor for grounding only)

Color Code:
5 Conductors: Black, White, Red, Green, Orange

*Data provided on this page is subject to change based on different manufacturers variances.

More Information
Wire Size14 AWG
# of Conductors5 Conductors
Conductor MaterialBare Copper
O.D. (Inches)0.45
Ampacity20
Jacket ColorBlack
