12 AWG, Hook-Up Wire, Tinned Copper, Type MTW/UL1015 Wire, 65 Strand, 250', 500', 1000' or 2500' Spool

SKU MTW12TC

$

0.350000

0.350000

/ft
How will you purchase this wire?
0.350000 0.350000
truck FREE SHIPPING ON ORDERS OVER $1000

Please Select Color(s)

Multiple colors can be selected

.... .... .... .... .... .... .... ....

Multiple lengths can be selected

250 500 1000 2500
Quantity

Select your preferred quantity for each color below. Add additional colors and lengths as needed.

12 AWG, Hook-Up Wire, Tinned Copper, Type MTW/UL1015 Wire, 65 Strand, 250', 500', 1000' or 2500' Spool

Grouped product items
Color Length (ft.)
Red Length 250 ft.
$87.50
Black Length 250 ft.
$87.50
Green Length 250 ft.
$87.50
White Length 250 ft.
$87.50
Blue Length 250 ft.
$87.50
Brown Length 250 ft.
$87.50
Red Length 500 ft.
$175.00
Black Length 500 ft.
$175.00
Green Length 500 ft.
$175.00
White Length 500 ft.
$175.00
Blue Length 500 ft.
$175.00
Brown Length 500 ft.
$175.00
Red Length 1000 ft.
$350.00
Black Length 1000 ft.
$350.00
Green Length 1000 ft.
$350.00
White Length 1000 ft.
$350.00
Blue Length 1000 ft.
$350.00
Brown Length 1000 ft.
$350.00
White w/ Blue Stripe Length 1000 ft.
$355.00
Green w/ Yellow Stripe Length 1000 ft.
$355.00
Red Length 2500 ft.
$875.00
Black Length 2500 ft.
$875.00
Green Length 2500 ft.
$875.00
White Length 2500 ft.
$875.00
Blue Length 2500 ft.
$875.00
Brown Length 2500 ft.
$875.00
White w/ Blue Stripe Length 2500 ft.
$880.00
Green w/ Yellow Stripe Length 2500 ft.
$880.00
truck FREE SHIPPING ON ORDERS OVER $1000
Product Details

Learn everything you want to know about this product to make an informed purchase

Specifications
  • Cable Type

    MTW - Machine Tool Wire

  • Wire Size

    12 AWG

  • # of Conductors

    1 Conductor

  • Conductor Material

    Bare Copper

  • O.D. (Inches)

    0.15

  • Insulation Material

    PVC - Polyvinyl Chloride

  • Direct Burial

    No

Data provided on this page is subject to change based on different manufacturers variances.
See Less
More information

STRIPED COLORS ARE NON-STOCK ITEMS & MAY TAKE 4-5 WEEKS TO SHIP

1000 FT Min for Stripe

12 AWG MTW/UL1015 Hook-Up Stranded Wire, 600V.  250ft, 500ft, 1000ft, or 2500' Spool.

Applications:
12 AWG UL1015 Type conductors are primarily used in control cabinets, in machine tool applications and appliance wiring applications. Applications requiring Type MTW conductor is appropriate for use in dry locations at 90°C, or not to exceed 60°C in wet locations or where exposed to oils or coolants. Applications requiring Type AWM conductor is appropriate for use at temperatures to not exceed 105°C in dry locations.

Conductor:
Tinned Copper

Insulation:
Polyvinyl Chloride (PVC)

Standards:
UL recognized AWM Style 1015 per 758. Passes VW-1 vertical flame test. CSA TEW or AWM

Specifications*:

Size: 12 AWG
Number of Strands: 65
Temp: 105°C
Insulation Thickness: 0.030 inches
Outside Diameter: 0.150 inches
Voltage: 600V

*Data provided on this page is subject to change based on different manufacturers variances.
